Profile Design Sonic Ergo 45AR Clip On Aerobar – 240mm

The Sonic Ergo 45AR aerobar offers comprehensive yet simple adjustment, ideally suited to riders wishing to add aerobars to their road, gravel or packing bike.

Performance

The Sonic Ergo platform offers a large range of adjustment in every dimension – enabling riders to optimise the comfort of their position.

This bar can be used for draft legal triathlon once shortened to meet the ITU rules.

Bracket

The Sonic bracket is the core product of their new generation bars,offering simple yet comprehensive adjustability.

Pairing this bracket with the ergo armrest offers industry leading fit options and greater comfort.

With the 45AR extensions this is the most versatile DL style bar they’ve ever product.

Fit Data

Armrest Offset: -70mm to -17.5mm in 7.5mm steps
Armrest Width: 124mm to 290mm in 18.5mm steps (With Extensions at 100mm)
Armrest Stack:  60mm (no riser kit) to 130mm in 5mm increments (With aftermarket Riser Kit)
Extension Width: 100mm

The extension length and rotation can be easily adjusted using the top bolt.

There are 80 distinct position options achievable just by moving the armrests – this gives an unprecedented level of adjustment for a shorty aerobar.

Orgin

Profile Design has a long history with shorty/DL style bars. This is their latest offering and the most adjustable yet. They wanted to create a bar that would be an easy and comfortable addition to road, gravel and packing bikes.

Specifications
